Produce features:
l Dual power inputs effectively improve supply reliability.
l Built-in electronic switch, compared with the conventional mechanical switch has higher security and stability.
l HD OLED display real-time display battery voltage input, the receiver operating voltage, operating voltage servos, CDI supply battery voltage, a single flight time, total flight time and other information.
l You can freely set the alarm input battery voltage, CDI-powered battery alarm voltage value (alarm value range :4-12V, use the tips alarm buzzer and LED)
l 9-channel inputs, 16 servo output (1 of 2), Article 9 channel control CDI flameout switch.
l Built-CDI remote flameout switch, making flying safer.
l Batteries and steering input interfaces directly connected, the input voltage is equal to the supply voltage servos, just use batteries of different voltage values to adapt to high voltage servos.
l Independent 5V linear regulator which provide a separate pure working power supply to the receiver.
l Dedicated receiver placement, to avoid accidental bombing has resulted in damage to the receiver.
Technology parameters:
l Input Voltage: 5-13V
l Output voltage : 5-13V
l Output Current : 0-20A
l Weight: 80g
l Size: 122mm*72mm*18mm
l Working temperature: -20 centigrade to 85 centigrade
