DS538MG Metal Gear Micro Servo 58g 7.0kg.cm/ 0.14sec For RC Model

Type:    DS538MG

Size:    20x40x38.5mm(0.78"x1.57"x1.51")

Weight:    59g

Working Voltage:    4.8V / 6.0V

Working Current:    250mA

Operating Rate:    0.14sec/60o

Stall Torque:    7.0kg.cm

Dead zone bandwidth:≤2uSec

Operating stroke:    40o one side pulse traveling 400μs

Potentiometer type:    2 slider/Indirect Drive

Gear Material:    Metal

Connector wire length:215mm

Operating temperature:-20 Centigrade to +60 Centigrade
