| Maximum takeoff weight | 5kg |
| Maximum working load capacity | 1kg |
| Standard operating load | 500g, less than 1000g recommended |
| Wingspan | 1200mm |
| Rotor | 10 inch carbon fiber folding paddle |
| Endurance | 45min (takeoff weight 4.5g) |
| Cruising speed | Standard: 125km/h; max 150km/h |
| Positioning navigation method | GNSS high-precision navigation and positioning (optional RTK cm-level navigation) |
| Fuselage material | Pure carbon fiber fuselage wing, the wing can be folded for takeoff automatically unfolded |
| Motor type | Brushless high-efficiency type large thrust motor |
| Power Battery | 10000mAh high energy density lithium battery |
| Control radius | About 5 km - according to the site communication environment |
| Mission altitude | Recommended less than 1000m |
| Maximum altitude | Recommended below 3000m, higher altitude requires optional highland power system and propeller |
| Take-off and landing mode | Barrel shot takeoff, automatic parachute landing; fully autonomous takeoff and landing |
| Support driving mode | Manual, GPS fixed point, autonomous flight |
| Protection type | Support low voltage protection function/uncontrolled return |
| Wind resistance level | Less than 7 levels |
| Hovering accuracy | Vertical: ±0.5 m, horizontal: ±1.5 m |
| Maximum ascent speed | 5m/s |
| Maximum descent speed | 3m/s |
| Operating temperature range | -20℃~50℃ |
| Dimension | Unfold: 1200*860*220mm, Fold: 110*850*120mm |
| Launch barrel length | 1050mmX138mmX138mm |
| Firing method | Compressed air |
| Cylinder capacity | 6L |
| Emission pressure | 1.5MPa-2MPa |
| Product List | |
| Item Name | Introduction |
| AeroVironment Switchblade | The whole machine 3.5KG, flight speed 26-40m/s |
| Air storage tank | 1.6MPA |
| Pump | 12V power supply |
| Launch switch | |
| Remote control | |
| Coyote Battery | 4S-15000mah 10C |
| Pump batteries | 3S-12000MAH |
| Launcher | |
